MORTERPLAS GARDEN MIN Membrane with polyester felt (FP) reinforcement and mastic with anti-root treatment.

Technical documentation

  • Logo Facebook
  • Logo Twitter
  • Logo Linkedin
  • Advantages
  • Application
  • Installation
  • Storage
  • Regulations
The stabilized and reinforced non-woven polyester felt (FP) reinforcement confers the best mechanical properties to the membrane:
· High tensile strength.
· Maximum puncturing resistance (static and dynamic).
· High tear resistance.
· Good dimensional stability.
· The APP plastomeric mastic, known for its robustness and excellent low-temperature flexibility, provides the membrane with high resistance to atmospheric agents and the maximum guarantee of durability.
· The membrane has excellent resistance to high temperatures, with allows it to be used in hot climates because it does not soften under high temperatures.
· Anti-root treatment that protects the waterproofing from roots, not rhizomes that produce bamboo, couch grass (Elymus repens)...etc.
· MORTERPLAS GARDEN MIN is applied in single-layer systems on green roofs or garden roofs with varying pitches.
· It can be applied as the top layer in multi-layer systems
· It is especially indicated for low-maintenance, light ecological roofs.
· It is applied on green roofs, where maximum use of rainwater and minimum external maintenance is required.
· It is applied in garden areas where details like upstands or vertical elements are exposed.
· It can be applied as a membrane to ensure the watertightness of underground structures

Finishing membrane in single layer systems for green roofs
· SUPPORT: The surface must be dry, firm, even, clean and free of loose materials.
· It can be applied completely adhered, partially adhered or floating. · To adhere the membrane to the support, the support is primed with EMUFAL I. Once dry, use flame to adhere the membrane.
· The flame is applied as uniformly as possible (the greater the heat, the greater the retraction) along the width of the membrane without reaching the overlap, which will be done later, since it is important that the temperature be the same in every area. The flame should be applied until the anti-adherent film pore opens.
· The membranes are installed in such a way that no more than three membranes overlap at the same point.
· Overlaps are flame-bonded, with a longitudinal overlap of at least 8 cm and a transversal overlap of at least 10 cm, first removing the minerals from the surface to ensure adherence.
· In the two-layer solution, the top membrane must be completely adhered to the bottom membrane, and it must be placed in the same direction so that the overlap lays approximately in the middle of the bottom membrane.
· Installation and measurements will be conducted in accordance with regulations of the UNE 104401 standard.
Rollo: 1 m x 8 m
Pallet: 200 m²
· In accordance with the EN 13707 standard. Certified with CE marking No. 0099/CPR/A85/0087
· Voluntary certification of the product with AENOR seal according to the same European standard.
· With DIT No. 516 Inverted roof systems “TEXLOSA® ROOFING SYSTEMS.”
· With DIT No. 562/10 MORTERPLAS/MOPLAS ZERO slope
· Quality System in accordance with ISO:9001
